HELIX E 12W Esprit Very shallow 300 mm / 12” subwoofer with aluminum die cast basket, honeycomb membrane and 2 x 2 Ohms dual voice coil The new esprit subwoofers really come into play when space is scarce but the desire for rich bass sound is at the top of the list. Although the black fiberglass coating on the outside is the only thing that makes them look different to their predecessors, what’s on the inside is completely new. Dual voice coils with an impedance of 2x2 Ohms predestine them for use in compact, sealed enclosures with the best in impulse response. Their extremely flat structural shape allows for forms never dreamed of before for the enclosure design. Highlights:
2 x 2 Ohms dual voice coil for more flexible speaker configurations
extremely stiff honeycomb membrane with fiberglass coating
massive and rigid aluminum die-cast baskets
very low mounting depth for shallow subwoofer constructions
massive gold-plated terminals
large maximum cone excursions thanks to wide rubber surround
T/S parameters optimized for use in compact sealed enclosures
|
Technische Daten
- an 2 Ohm
Specifications: Power handling RMS / max
400 / 600 Watts
Sensitivity 88 dB 1W / 1m
Impedance 2 x 2 Ohms
Resonance frequency
37 Hz
Qms 4,3
Qes 0,55
Qts 0,49
VAS 48 liters
Linear cone excursion
+/- 5,5 mm / 0.22"
Monting depth
87 mm / 3.43"
| |
